General

Frequency Range:

UHF: 350-470MHz VHF: 136-174MHz

RF Output Power:

UHF: 1W/ 4W VHF: 1W/ 5W

Channel Capacity:

1024(64 zones with 256 channels per zone)

Channel Spacing: 12.5kHz / 20kHz / 25kHz.

Digital Protocol: ETSI-TS102 361-1, -2, -3

Operating Voltage :7.7V (rated)

Battery: 2400mAh Li-polymer anti-counterfeit

Battery Life (5/5/90, Digital, High TX Power):

24h (GNSS off), 20h (GNSS on)

Dimensions (H x W x D): 132 x 55 x 29.5mm

Weight (with antenna and battery): 310g

Display:

LCD, 320×240 pixel, 262,000 colours, 2.4 inch, 10 rows

Keypad: Full keypad

Dedicated Emergency Button (Top Key): Support

Bluetooth (Optional): BT5.0BLE+EDR

GNSS(Optional): GPS, GLONASS, BDS

Programmable Buttons: 8

Dust & Water Intrusion: IP68

Receiver Sensitivity (Digital): 0.18 μV (5% BER)

Receiver Sensitivity (Analog):

0.18μV (12dB SIN AD) 0.16μV (Typical) (12dB SIN AD)

Key Features

Operation Mode:

Analogue/DMR Conventional, IP multi-sites, XPT, DMR Simulcast, DMR Trunking(licensed)

Call type:

Private Call, Group Call, All Call, Broadcast Call, Emergency Call, PSTN/PABX Call, Call Alert, Call Priority

Data Service:

Text Message, Status Message, Quick Text Message

Safety:

Emergency, Remote Monitor, Man Down, Lone Worker, Stun/Revive, Authentication, Air Interface Encryption, End-to End Encryption,

Analog:

Scramble,2 Tone, HDC1200, CTCSS/CDCSS
